PCB Eyelets

A PCB eyelet is a small metal ring designed to be installed in a circuit board. It might look simple, but it plays an important role. People use them to create strong and reliable holes in a PCB. This little component helps make sure connections don't get damaged during assembly or use. Nuote Metals are happy to help you to know more about eyelets for PCB.

Send Inquiry

Product Description

Introduction of PCB eyelets

The main job of a PCB eyelet is to reinforce a hole. It is typically made of brass and often plated with tin or solder. This makes it easy to solder components to it. When pressed into the board, a PCB eyelet strengthens the hole, preventing cracks in the copper trace. It acts like a durable sleeve that protects the delicate circuit board material.

PCB eyelets drawing as below:

Product Parameter (Specification)

Material	Brass
Surface Treatment	Clean, zinc plating, nickecl plating, silver plating, as requested
Certificate	Rohs compliant
Shank Diameter	0.8-10mm
Tolerance	+/-0.05mm
Application	Suitable for use in various industries, including automotive, aerospace, electrical and electronics, etc.
Quality Control	100% whole range inspection through production ensures that each product meets the ISO standard, guaranteeing high-quality products.

PCB eyelets application show:

Product Feature And Application

You will find PCB eyelets used in many electronic products. They are perfect for places that need a strong connection point, like a transformer or a large component leg. A PCB eyelet is also common in test points, where a probe might connect repeatedly. In switches or connectors, the PCB eyelet ensures the mechanical stress is on the metal sleeve, not the fragile board itself. They are essential for making electronics that last.
